Edited February 2023


Missile Designation KN-01
Variants Based on P-15 Termit (Russian); CSS-C-2 Silkworm (Chinese)
Mobility and Role Ground-, air-, and ship-launched Anti-ship cruise missile
Designer/Producer Origin: MKB Raduga (Russian); Redesigned by North Korea
Range 110km or 160-300km
Warhead Type and Weight 500kg HE warhead

3000kg missile launch weight

Guidance System/Accuracy Active Radar Seeker; Internal Navigation System; Infrared Homing
Cruise Altitude 100m-300m
Propellant Solid-fuel booster; liquid-fuel sustainer
IOC/Retirement 1993; Operational
Status/Number of Units Unknown
Launch Vehicles Missile boats: Komar-class, Osa-class;

Corvettes: Tarantul-class, Nanuchka-class;

Frigates: Koni-class, Kotor-class;

Destroyers: Kildin-class, Kashin-class;


The KN-01 is a North Korean anti-ship cruise missile that is an extended-range variant of the Soviet P-15 Termit (SS-N-1 Styx), and China’s CSS-C-2 Silkworm. North Korea received these missiles from both the Soviets and Chinese on several occasions from 1967 to 1991, with Russia delivering the final order following the fall of the Soviet Union in 1991. The missile’s design was exported from the Soviet Union to China, from where it is believed the North Koreans attained it.[1] Since 1993, North Korea has continued to work on the KN-01 to extend its range, and possibly arm it with a nuclear warhead.[2] North Korea’s testing of the KN-01 frequently worry neighboring countries – Japan and South Korea – as often the missiles will fall into the sea close to either countries territory.[3]

North Korea tested an air-launched version of the KN-01, carried by a Il-28, on at least two occasions in 2011.

Strategic Implications

North Korea has tested the KN-01 repeatedly since its first flight test in 1993.[4] The North Koreans work to continually improve the missile, such as the 2015 test with an integrated turbojet engine. North Korea reportedly aims to make its submarines capable of launching the KN-01. An SLBM, if fitted with a nuclear warhead, would give the North Koreans second-strike capability, making them a greater threat to start a nuclear exchange. However, South Korean officials have determined that the missiles currently have no electronic countermeasure (ECM) capabilities, making them easy to interfere with and knock down with jammers.[5]Despite this, the KN-01 will most likely be supplanted by North Korea’s more advanced ASCMs such as the Kumsong-3.
