Allied Air Defense Sensor Systems

Air Defense Sensor System	Country	Wavelength	Targets
S1850M	France, Italy, and United Kingdom	L-Band	Aircraft, Ballistic Missiles, and Stealth Targets
European Multi-Function Phased Array Radar (EMPAR)	Italy and France	C-Band	Aircraft and Missiles
Preparatory System for IR Early Warning (SPIRALE)	France	S/X-Band	Ballistic Missiles
VERA S/M	Czech Republic	Wide Band (1.0 to 18 GHz)	Military ‘Invisible’ Aircraft
Active Phased Array Multi-Function Radar (APAR)	Denmark	X-Band	Supersonic High-Drivers, Supersonic Sea Skimmers, and Stealth Targets
CEROS 200 Fire Control System (FCS)	Sweden	Ku-Band	Advanced Sea Skimming Missiles and Asymmetric Surface Threats
Signaal Multi-Beam Acquisition Radar for Tracking L-Band (SMART-L)	Netherlands	L-Band	Military Patrol Aircraft, Stealth Missiles, and Ballistic Missiles
Signaal Multi-Beam Acquisition Radar for Tracking S-Band (SMART-S)	Netherlands	S-Band	Small High-Speed Anti-Ship Missiles, Sea Skimming Missiles, Stealth Missiles, Helicopters, and UAVs
KALKAN Air Defense Radar	Turkey	X-Band	Helicopters, Hovering Helicopters, Cruise Missiles, and UAVs
3D Lanza	Spain	L-Band	Theater Ballistic Missiles
SAMPSON Radar	United Kingdom	S-Band	Sea Skimming Missiles, Stealth Missiles, and Ballistic Missiles
Giraffe Radar	Australia	C-Band	Rocket, Artillery, and Mortar Rounds
ELM-2090S Spectra	Israel	S-Band	Ballistic Missiles, Air Breathing Targets, and Satellites
ELM-2090 Terra	Israel	S/UHF-Band	Ballistic Missiles, Satellites, Air Breathing Targets, and Low Radar-Cross-Section (RCS) Class Stealth Targets
ELM-2090U Ultra	Israel	UHF-Band	Small-Target Detection at Long Ranges, Air Defense, and Early Warning and Detection
ELM-2106 ATAR	Israel	L-Band	Low Velocity Targets, Ultra-Light Targets, Helicopters, Unmanned Aerial Vehicles, and Fighter Aircraft

U.S. Partners - Air Defense, Sensor

3D Lanza

Quick Facts Role and Mobility Long-Range Volumetric Air Surveillance and Air Traffic Control; Fixed Position Frequency L-Band Range 470 km

U.S. Partners - Air Defense, Sensor

Active Phased Array Radar (APAR)

Quick Facts Role and Mobility Air and Surface Target Tracking, Horizon Search, Volume Search, Surface Naval Gunfire Support, and Missile

U.S. Partners - Air Defense, Sensor

CEROS 200 Fire Control System (FCS)

Quick Facts Role and Mobility Threat Detection & Tracking; Ship-based Frequency Ku-band, 15.5-17.5 GHz Range Long-range Air Defense Interceptor Systems

U.S. Partners - Air Defense, Command and Control, Sensor

E-7 Wedgetail

Quick Facts Role Airborne early warning and control (AEW&C) and command and control battle management (C2BM) Targets Aircraft, cruise missiles

U.S. Partners - Air Defense, Sensor

ELM-2090 Terra Dual Band Radar

Quick Facts Role and Mobility Early Warning and Tracking, Extended Air and Missile Defense Coverage, and Long-Range Detection; Fixed Position

U.S. Partners - Air Defense, Sensor

ELM-2090S Spectra

Quick Facts Role and Mobility Early Detection, Search and Track: Road- and Ship-Mobile Frequency S-Band Range Very Long Air Defense

U.S. Partners - Air Defense, Sensor

ELM-2090U Ultra

Quick Facts Role and Mobility Small-Target Detection at Long Ranges, Air Defense, and Early Warning and Detection; Fixed Position Radar

U.S. Partners - Air Defense, Sensor

ELM-2106 ATAR

Quick Facts Role and Mobility Medium-Range Tactical Air Defense and Surveillance; Fixed or Road-Mobile Frequency L-Band Range Fighter Aircraft: 70-110

U.S. Partners - Air Defense, Sensor

European Multifunction Phased Array Radar (EMPAR)

Quick Facts Role and Mobility Threat Detection and Tracking; Ship-Mobile Frequency C-Band Range 150 km Air Defense Interceptor Systems Principal

U.S. Partners - Air Defense, Sensor

Giraffe Agile Multi Beam Radar

Quick Facts Role and Mobility Air/Surface Surveillance and Tracking, Early Warning, and Target Identification; Road- and Ship-Mobile Frequency C-Band Range

U.S. Partners - Air Defense, Sensor

KALKAN Air Defense Radar

Quick Facts Role and Mobility Low and Medium Air Defense; Road-mobile Frequency X-Band Range 100 km Air Defense Interceptor Systems

U.S. Partners - Air Defense, Sensor

S1850M

Quick Facts Role and Mobility Wide Area Search, Long-Range detection of conventional aircraft and medium-range detection of small stealth missiles;

U.S. Partners - Air Defense, Sensor

SAMPSON Radar

Quick Facts Role and Mobility Long and medium-range search, surface picture search, high-speed horizon search, high-angle search and track, multiple

U.S. Partners - Air Defense, Missile Defense, Sensor, Sensor

SMART-L Radar (The Netherlands and Others)

Quick Facts Mobility Sea-based; highly mobile Role Deployed by Netherlands, Denmark, Germany, South Korea (SMART-L derivative is deployed by British,

U.S. Partners - Air Defense, Sensor

SMART-S Radar (The Netherlands and Others)

Quick Facts Role and Mobility Medium and Long-Range Air and Surface Surveillance, Early Warning; Ship-mobile Frequency S-Band Range Medium Range:

U.S. Partners - Air Defense, Sensor

SPIRALE

Quick Facts Role and Mobility Early Warning; Space-Based Frequency S-Band for Communications, X-Band for Transmissions Range N/A Air Defense Interceptor

U.S. Partners - Air Defense, Sensor

Vera S/M

Quick Facts Role and Mobility Threat Detection and Tracking; Fixed Position Frequency 1-18 GHz (Multiple Bands) Range 450 km Air
